AMD RYZEN 5 3600 Desktop Processor (Tray type) with Asus Rog STRIX B450-F Gaming II Motherboard
This product is no longer available.
100% Original
Free Delivery
30 Days Return
Chat with Us!
Share this product:
AMD RYZEN 5 3600 Desktop Processor (Tray type)
-no box included, processor is already installed on the motherboard.
SpecificationsCPU Cores = 6Threads = 12Base Clock = 3.6GHzMax Boost Clock = Up to 4.2GHzTotal L1 Cache = 384KBTotal L2 Cache = 3MBTotal L3 Cache = 32MBUnlocked = YesCMOS = TSMC 7nm FinFETPackage = AM4PCI Express® Version = PCIe 4.0 x16Thermal Solution (PIB) = Wraith StealtThermal Solution (MPK) = Wraith StealthDefault TDP / TDP = 65WMax Temps = 95°C
Asus Rog STRIX B450-F Gaming II Motherboard
SPECS:
CPU
AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
* Refer to for CPU support list
Chipset
AMD B450
Memory
4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
Dual Channel Memory Architecture
* Refer to for the Memory QVL (Qualified Vendors Lists).
Graphic
1 x HDMI 2.0b
1 x DisplayPort 1.2
*Graphics specifications may vary between CPU types.
Integrated Graphics Processor
Multi-GPU Support
Supports AMD 3-Way CrossFireX™ Technology
Expansion Slots
2 x PCIe 3.0 x16 (x16 or x8/x4)
1 x PCIe 2.0 x16 (x4 mode) *
3rd/2nd/1st Gen AMD Ryzen™ Processors
1 x PCIe 3.0 x16 (x4 mode)
AMD B450 chipset
3 x PCIe 2.0 x1
1 x PCIe 3.0 x16 (x8 mode)
AMD Athlon™ with Radeon™ Vega Graphics Processors
Storage
3rd/2nd/1st Gen AMD Ryzen™ Processors :
1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*
1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
1 x M.2_2 socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)
Total supports 2 x M.2 slot(s) and 6 x SATA 6Gb/s ports
2 x SATA 3Gb/s port(s),
2 x SATA 6Gb/s port(s)
2 x SATA 6Gb/s port(s),
AMD B450 chipset :
1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
AMD Athlon™ with Radeon™ Vega Graphics Processors :
4 x SATA 6Gb/s port(s),
Support Raid 0, 1, 10
LAN
Intel® I211-AT 1Gb Ethernet
ASUS LANGuard
Audio
- Audio Shielding
ROG SupremeFX7.1-Channel High Definition Audio CODEC S1220A
- Premium Japanese audio capacitors
- Audio Cover
- Optical S/PDIF out header(s) at mid-board
- Dual OP Amplifiers
- Impedance sense for front and rear headphone outputs
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality120dBSNR stereo playback outputand113dBSNR recording input
- Supports up to 32-Bit/192kHz playback *
Audio Feature :
- SupremeFX Shielding™ Technology
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
USB Ports
4 x USB 3.2 Gen 1 port(s)(3 x Type-A +1 x USB Type-C)
Front USB Port
2 x USB 3.2 Gen 2 port(s)(2 x Type-A)
Rear USB Port
2 x USB 3.2 Gen 1 port(s)
2 x USB 2.0 port(s)
Software Features
ROG Exclusive Software- RAMCache III- ROG CPU-Z- GameFirst VI- Sonic Studio III + Sonic Studio Virtual Mixer - Sonic Radar III- Overwolf - Anti-virus softwareASUS Exclusive Software FeaturesArmoury Crate- Aura Creator- Aura SyncAi noise cancelling microphone AI Suite 3:- 5-Way Optimization by Dual Intelligent Processors 5TPUEPUDIGI+ VRMFan Xpert 4Turbo app- EZ updateAI ChargerUEFI BIOSASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode
ASUS Special Features
Aura Sync- Standard RGB header(s)- Addressable Gen 2 RGB header(s)ASUS Q-Design - ASUS Q-DIMM- ASUS Q-LED (DRAM [yellow],CPU [red], VGA [white], Boot Device [yellow green)- ASUS Q-SlotASUS Thermal Solution- Aluminum M.2 heatsinkASUS EZ DIY-BIOS FlashBack™ button-BIOS FlashBack™ LED-Clear CMOS header-Pre-mounted I/O shield- SafeSlot
Back I/O Ports
1 x Intel® I211-AT 1Gb Ethernet
2 x USB 3.2 Gen 2
3 x USB 3.2 Gen 1 Type-A
1 x USB 3.2 Gen 1 USB Type-C
1 x BIOS FlashBack Button(s)
1 x PS/2 keyboard/mouse combo port(s)
1 x DisplayPort
1 x HDMI
2 x USB 2.0
1 x Optical S/PDIF out
5 x Audio jack(s)
Internal I/O Ports
1 x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
1 x M.2 Socket 1 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x CPU Fan connector(s)
1 x CPU OPT Fan connector(s)
3 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x Addressable RGB header
1 x AAFP connector
2 x Aura RGB Strip Header(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x TPM header
1 x COM port(s) connector(s)
6 x SATA 6Gb/s connector(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x System panel(s)
1 x Thermal sensor connector(s)
1 x Clear CMOS jumper(s)
Accessories
1 x M.2 SSD screw package(s)
1 x M.2 Rubber Package(s)
User´s manual
4 x SATA 6Gb/s cable(s)
1 x Supporting DVD
1 x ROG Strix stickers
1 x Cable ties pack(s)
1 x Extension Cable for RGB strips (80 cm)
1 x Extension cable for Addressable LED
1 x ROG Thank you card
BIOS
256 Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PME, PXE
Operating System
Windows® 10 64-bit
Form Factor
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
