Product Name: Itw | Asus Mini PC All in One Desktop PC ASUS NUC 14 Pro Mini PC Tall PC Kit RNUC14RVHU500001I
Key Feature
• Performance: Delivers best-in-class performance among comparable mini-PC offerings
• Manageability: Most comprehensive mini-PC with Intel vPro® Enterprise for exceptional security, manageability, and stability
• AI Ready: Harnesses the prowess of Intel® Core™ Ultra processors’ three AI engines for high throughput, low power, and fast response
• Wi-Fi Sensing: Takes advantage of Wi-Fi sensing to deliver instant availability while reducing power consumption
• Wireless Connectivity: Delivers seamless connectivity for certified Bluetooth® dongle-free experiences
• Customizable: Designed for toolless chassis access making upgrades easier, safer, and faster
Specification
CPU
• 14th Generation Intel® Core™ Ultra 5 125H
• 14 Processor Cores (4P+8E+2LE), 18 threads, 18MB Smart Cache, 40W TDP
Chipset: Integrated
NPU: Intel® AI Boost (1.4Ghz)
AI Software Frameworks: OpenVINO™, WindowsML, DirectML, ONNX RT
Graphics: Intel® Arc™ Graphics
Memory: 2 x SO-DIMM, DDR5-5600 max of 96GB (48GB x 2)
Storage
• 1 x M.2 22x80 key M slot for PCIe x4 Gen 5 NVMe SSD
• 1 x M.2 22x42 key M slot for PCIe x4 Gen 4
• 1 x SATA 2.5in SATA support
Wireless Network: Intel® AX211 (Gig+), Wi-Fi 6E, Bluetooth 5.3
LAN: 2.5G Ethernet, 10/100/1000/2500 Mbps
Wake On Lan support: Wake on from S5 & Modern Standby
TPM: fTPM 2.0
Interface
Front I/O
• 1 x USB 3.2 Gen2 Type-A (with BC1.2, 5V/0.9A, 10Gbps)
• 1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
Side I/O
• 1 x Kensington Lock slot
Rear I/O
• 2 x Thunderbolt™ 4 (5V/3A, 40Gbps)
• 1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
• 1 x USB 2.0 (5V/0.5A)
• 2 x HDMI 2.1 TMDS Compatible (4K@60Hz), with built-in CEC per port
• 1 x 2.5G RJ45 LAN
• 1 x DC-in
Physical
• Dimension: "H" 117 x 112 x 54 mm (0.7L)
• Weight: "H" 0.57 kg(barebone) / "K" 0.50 kg (barebone)
Power Supply*: 20Vdc/19Vdc, 6.0A/6.32A 120W Power Adapter
