Product Name: Itw | ASUS Motherboard ROG Strix X870E-E Gaming Wifi ATX AM5 DDR5
Specification
CPU
> AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*
Chipset
> AMD X870E
Memory
> 4 x DIMM slots, max. 192GB, DDR5 Supports up to 8000+MT/s(OC) with Ryzen™ 9000 Series Processors, 8400+MT/s(OC) with Ryzen™ 8000 Series Processors, 8000+MT/s(OC) with Ryzen™ 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM*
> Dual Channel Memory Architecture
> Supports AMD EXTended Profiles for Overclocking (EXPO™)
> NitroPath DRAM Technology
> ASUS Enhanced Memory Profile (AEMP)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration.
* Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function
Graphics
> 1 x HDMI™ port**
> 2 x USB4® (40Gbps) ports support USB Type-C® display outputs***
* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
** Supports max. 4K@60Hz as specified in HDMI 2.1.
*** Supports max. 4K@60Hz as specified in DisplayPort 1.4a
**** VGA resolution support depends on processors' or graphic cards' resolution.
Storage
> Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*
> AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
- M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**
- M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)**
> AMD Ryzen™ 8000 Series Desktop Processors*
- M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- M.2_2 slot (Key M), type 2242/2260/2280 (Not supports)***
- M.2_3 slot (Key M), type 2242/2260/2280/22110 (Not supports)***
> AMD X870E Chipset
- M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- 4 x SATA 6Gb/s ports
*AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10. RAID 5 Funciton is only supportted by AMD Ryzen™ 9000series CPU.
** M.2_2 & M.2_3 slots share bandwidth with PCIEX16(G5). When M.2_2 & M.2_3 are occupied with SSD devices, PCIEX16(G5) will run x8 only.
*** M.2_2 & M.2_3 will be disabled when using AMD Ryzen™ 8000 Series Desktop Processors.
USB
> Rear USB (Total 13 ports)
- 2 x USB4® (40Gbps) ports(2 x USB Type-C®)
- 1 x USB 20Gbps port (1 x USB Type-C® with up to 30W PD Fast-charge)**
- 10 x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C®)
> Front USB (Total 11 ports)
- 1 x USB 20Gbps connector (supports USB Type-C®)
- 2 x USB 5Gbps headers support additional 4 USB 5Gbps ports
- 3 x USB 2.0 headers support additional 6 USB 2.0 ports
* USB Type-C® power delivery output: 5V/3A
** USB Type-C® power delivery output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A
Audio
> ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback
> Audio Features
- Audio Shielding
- Savitech SV3H712 AMP
- Gold-plated audio jacks
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
* The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
Back Panel I/O Ports
> 2 x USB4® (40Gbps) ports (2 x USB Type-C®)
> 1 x USB 20Gbps port (1 x USB Type-C® with up to 30W PD Fast-charge)
> 10 x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C®)
> 1 x HDMI™ port
> 1 x Wi-Fi Module
> 1 x Realtek 5Gb Ethernet
> 2 x Gold-plated audio jacks
> 1 x Optical S/PDIF out port
> 1 x BIOS FlashBack™ button
> 1 x Clear CMOS button
Form Factor
> ATX / 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
