Product Name: ITW | Cooler Master MWE 750W Bronze V2 80+ Bronze Non-modular PSU (MPE-7501-ACABW-BUS)
Specification
✎ Model: MPE-7501-ACABW-B
✎ ATX Version: ATX 12V V2.52
✎ PFC: Active PFC
✎ Input Voltage: 200-240Vac
✎ Input Current: 10-6A
✎ Input Frequency: 50-60Hz
✎ Dimensions (L x W x H): 140 x 150 x 86 mm
✎ Fan Size: 120mm
✎ Fan Bearing: HDB
✎ Fan Speed: 2400 RPM
✎ Noise Level @ 20%: 11.12 dBA
✎ Noise Level @ 50%: 20.3 dBA
✎ Noise Level @ 100%: 39.5 dBA
✎ Efficiency: 88% Typically
✎ 80 PLUS Rating: 80 PLUS Bronze EU 230V
✎ ErP 2014 Lot 3: Yes
✎ Power Good Signal: 100 - 500 ms
✎ Hold Up Time: >14ms at 100% Full Load@230Vac
✎ MTBF: >100,000 Hours
✎ Protections: OVP, OPP, SCP, UVP, OTP
✎ Regulatory: CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
✎ ATX 24 Pin Connectors: 1
✎ EPS 4+4 Pin Connectors: 1
✎ EPS 8 Pin Connector: 1
✎ SATA Connectors: 6
✎ Peripheral 4 Pin Connectors: 3
✎ PCI-e 6+2 Pin Connectors: 4
✎ Series: MWE Bronze Series
✎ 80 Plus: Bronze
✎ Modular: Non Modular
✎ Wattage: 750W
